Spesifikasi Motor
| Tipe Mesin |
4 Langkah, 4-Valve, eSP+ |
| Sistem Pendingin |
Pendingin Cairan |
| Sistem Pengapian |
PGM-FI (Programmed Fuel Injection) |
| Volume Langkah |
156,9 cc |
| Diameter x Langkah |
60 x 55,5 mm |
| Perbandingan Kompresi |
12 : 1 |
| Daya Maksimum |
11,3 kW (15,4 PS) / 8.500 rpm |
| Torsi Maksimum |
13,8 Nm (1,5 kgf.m) / 7000 rpm |
| Tipe Transmisi |
Otomatis, V-Matic |
| Tipe Starter |
Elektrik |
| Tipe Kopling |
Otomatis, Sentrifugal, Tipe Kering |
| Tipe Minyak Pelumas |
Basah |
| Kapasitas Minyak Pelumas |
0,8 liter (Penggantian Periodik) |
| Tipe Rangka |
Underbone – eSAF (enhanced Smart Architecture Frame) |
| Ukuran Ban Depan |
110/90 – 12 M/C Tubeless |
| Ukuran Ban Belakang |
130/80 – 12 M/C Tubeless |
| Rem Depan |
220 mm Cakram Hidrolik (ABS) & 190 mm Cakram Hidrolik (CBS) |
| Rem Belakang |
220 mm Cakram Hidrolik (ABS) & Tromol (CBS) |
| Sistem Pengereman |
Anti-Lock Braking System (ABS) & Combi Brake System (CBS) |
| Tipe Suspensi Depan |
Teleskopik |
| Tipe Suspensi Belakang |
Swing Arm dengan Suspensi Tunggal |
| Panjang x Lebar x Tinggi |
1.886 x 706 x 1.133 mm (ABS) & 1.886 x 701 x 1.133 mm (CBS) |
| Jarak Sumbu Roda |
1.275 mm |
| Jarak Terendah ke Tanah |
151 mm |
| Tinggi Tempat Duduk |
768 mm |
| Berat Kosong (Curb Weight) |
118 kg (ABS) & 115 kg (CBS) |
| Kapasitas Tangki Bahan Bakar |
5,5 liter |
| Sistem Pengapian |
Full Transisterized |
| Tipe Baterai/Aki |
MF 12V-5Ah |
| Tipe Busi |
NGK LMAR8L-9 |
