Spesifikasi Motor
| Tipe Motor |
In-Wheel Brushless Motor |
| Power Maksimal |
1,7 kW/540 rpm |
| Torsi Maksimal |
90 Nm/25 rpm |
| Rated Power |
0,58 kW |
| Diameter x Langkah |
60 x 55,5 mm |
| Perbandingan Kompresi |
12 : 1 |
| Daya Maksimum (mesin) |
11,8 kW (16 PS) / 8.500 rpm |
| Daya Maksimum (motor) |
1,4 kW / 3.000 rpm |
| Torsi Maksimum (mesin) |
14,7 Nm (1,5 kgf.m) / 6.500 rpm |
| Torsi Maksimum (motor) |
4,3 Nm / 3.000 rpm |
| Tipe Baterai |
Lithium-ion |
| Voltase Baterai |
50,26 V |
| Kapasitas Baterai |
29,4 Ah |
| Tipe Rangka |
Underbone |
| Ukuran Ban Depan |
90/90 – 12 44J |
| Ukuran Ban Belakang |
100/90 – 10 56J |
| Tipe Rem Depan |
Cakram Hidrolik |
| Tipe Rem Belakang |
Tromol |
| Sistem Pengereman |
Combi Brake System(CBS) |
| Tipe Suspensi Depan |
Teleskopik |
| Tipe Suspensi Belakang |
Suspensi Ganda |
| Panjang X Lebar X Tinggi |
1795 x 680 x 1080 mm (EM1 e:)
1860 x 680 x 1080 mm (EM1 e: PLUS) |
| Jarak Sumbu Roda |
1300 mm |
| Jarak Terendah Ke Tanah |
135 mm |
| Tinggi Tempat Duduk |
740 mm |
| Berat Kosong (Curb Weight) |
94 kg (EM1 e:)
96 kg (EM1 e: PLUS) |
| Berat Baterai |
10,2 kg |
| Waktu Pengisian Baterai |
(0-100%) 6 jam / (25-75%) 2,7 jam |
