Spesifikasi Motor
| Tipe Mesin |
4-stroke SOHC 2-Valve |
| Kapasitas Mesin |
124 cc |
| Sistem Suplai Bahan Bakar |
PGM-FI |
| Diameter X Langkah |
50 x 63,1 mm |
| Tipe Transmisi |
Manual, 4-speed |
| Rasio Kompresi |
10 : 1 |
| Daya Maksimum |
7,2 kW / 7.500 rpm |
| Torsi Maksimum |
10,4 nM / 6.250 rpm |
| Tipe Starter |
Electric |
| Tipe Kopling |
Wet, Multiple With Coil Spring |
| Sistem Pendingin Mesin |
Air-cooled |
| Tipe Rangka |
Backbone, Steel |
| Tipe Suspensi Depan |
Telescopic Front Suspension |
| Tipe Suspensi Belakang |
Twin Rear Suspension |
| Ukuran Ban Depan |
70/90-17 M/C 38P (Tubeless) |
| Ukuran Ban Belakang |
80/90-17 M/C 50P (Tubeless) |
| Rem Depan |
Hydraulic Disc |
| Rem Belakang |
Mechanical Leading Trailing |
| Panjang X Lebar X Tinggi |
1.915 X 720 X 1.000 mm |
| Tinggi Tempat Duduk |
780 mm |
| Jarak Sumbu Roda |
1.245 mm |
| Jarak Terendah Ke Tanah |
125 mm |
| Curb Weight |
110 kg |
| Kapasitas Tangki Bahan Bakar |
3,7 L |
| Kapasitas Minyak Pelumas |
0,8 L (Periodic Exhange) |
| Tipe Battery Atau Aki |
12V-3Ah |
| Tipe Busi |
NGK CPR7EA-9S |
| Tipe Pengapian |
Full Transisterized |
| Headlight |
Hi 10,1 W x 1LED – Low 5,1 W x 1LED |
